• 12V pwr outlet
• Air conditioning
• AM/FM stereo radio w/cassette, (4) speakers, CD changer control
• Analog instrument cluster w/tachometer, 120 MPH speedometer
• Black vinyl floor covering
• Cigar lighter
• Cloth 40/20/40 split bench seat w/center armrest
• Cloth covered sun visors w/RH mirror
• Driver/passenger assist handles
• Front dome lamp
• Vinyl door trim panels

• 136-amp alternator
• 16" x 7" styled steel wheels
• 20 gallon fuel tank
• 3.21 axle ratio
• 6'6" pickup box
• 600-amp maintenance-free battery
• Conventional spare tire & wheel w/winch-type carrier
• Front stabilizer bar
• HD front/rear shock absorbers
• Independent front suspension
• P245/70R16 on/off-road BSW tires
• Pwr front disc/rear drum brakes-inc: rear anti-lock
• Pwr rack & pinion steering
• Rear wheel drive

• 3-point outboard seating position seatbelts w/front height adjusters, center lap belts
• Driver & front passenger airbags w/passenger on/off switch
• Dual note horn
• Rear anti-lock brakes

3.7L (226) SMPI V6 "MAGNUM" ENGINE

• (STD)

• Power Door Locks
• Cruise Control
• Cassette
• Topper
• Rear Wheel Drive
• Tires - Front On/Off Road
• Tires - Rear On/Off Road
• Conventional Spare Tire
• Steel Wheels
• Power Steering
• ABS
• Front Disc/Rear Drum Brakes
• Intermittent Wipers
• Variable Speed Intermittent Wipers
• Cloth Seats
• Split Bench Seat
• A/C
• AM/FM Stereo
• Cassette
• Power Outlet
• Passenger Vanity Mirror
• Driver Air Bag
• Passenger Air Bag
• Passenger Air Bag On/Off Switch
• ABS

• Brakes
• Brake ABS System: Rear Wheel
• Brake Type: Pwr
• Disc - Front (Yes or ): Yes
• Drum - Rear (Yes or ): Yes
• Front Brake Rotor Diam x Thickness (in): 12.1 x 1.0
• Rear Drum Diam x Width (in): 11.0 x 2.25
• Cargo Area Dimensions
• Cargo Box (Area) Height (in): 17.5
• Cargo Box Length : Floor (in)
• Cargo Box Width : Floor (in)
• Cargo Box Width : Top, Rear (in)
• Cargo Box Width : Wheelhousings (in)
• Cargo Volume (ft³): 46.0
• Tailgate Width (in): 53.3
• Cooling System
• Total Cooling System Capacity (qts): 14.3
• Electrical
• Cold Cranking Amps : 0° F (2nd)
• Cold Cranking Amps : 0° F (Primary)
• Maximum Alternator Capacity (amps): 136
• Maximum Alternator Watts: 1904
• Exterior Dimensions
• Cab to Axle (in): 39.2
• Front Bumper to Back of Cab (in): 107.2
• Ground Clearance, Front (in): 9.4
• Ground Clearance, Rear (in): 9.3
• Ground to Top of Load Floor (in): 29.4
• Height, Overall (in): 66.0
• Length, Overall w/o rear bumper (in): 196.0
• Overhang, Front (in): 34.4
• Overhang, Rear w/o bumper (in): 49.6
• Wheelbase (in): 112.0
• Width, Max w/o mirrors (in): 71.6
• Frame
• Frame Type: Ladder
• Fuel Tank
• Fuel Tank Capacity, Approx (gal): 20
• Fuel Tank Location: Inboard LH
• Interior Dimensions
• Front Head Room (in): 40.0
• Front Hip Room (in): 54.9
• Front Leg Room (in): 41.9
• Front Shoulder Room (in): 57.2
• Passenger Capacity: 3
• Mileage
• EPA Fuel Economy Est - City (MPG): 17
• EPA Fuel Economy Est - Hwy (MPG): 22
• Steering
• Steering Ratio (:1), On Center: 14.8
• Steering Type: Pwr Rack & Pinion
• Turning Diameter - Curb to Curb (ft): 35.9
• Summary
• Body Code: 112.0" WB
• Body Style: Reg Cab 6'6" Bed
• Vehicle Name: Dodge Dakota
• Suspension
• Axle Capacity - Front (lbs): 3100
• Axle Capacity - Rear (lbs): 3850
• Axle Ratio (:1) - Rear: 3.21
• Axle Type - Rear: Semi-Floating Hypoid
• Shock Absorber Diameter - Front (mm): 30.2
• Shock Absorber Diameter - Rear (mm): 30.2
• Spring Capacity - Front (lbs): 3100
• Spring Capacity - Rear (lbs): 3850
• Suspension Type - Front: Independent Coil
• Suspension Type - Rear: Leaf
• Tires
• Front Tire Capacity (lbs): 1903
• Front Tire Order Code: TS8
• Front Tire Size: P245/70R16
• Rear Tire Capacity (lbs): 1903
• Rear Tire Order Code: TS8
• Rear Tire Size: P245/70R16
• Revolutions/Mile : 45 mph - Front
• Revolutions/Mile : 45 mph - Rear
• Revolutions/Mile : 45 mph - Spare
• Spare Tire Capacity (lbs): 1903
• Spare Tire Order Code: TS8
• Spare Tire Size: P245/70R16
• Trailering
• Dead Weight Hitch - Max Tongue Wt. (lbs): 490
• Dead Weight Hitch - Max Trailer Wt. (lbs): 4900
• Fifth Wheel Hitch - Max Tongue Wt. (lbs): N/A
• Fifth Wheel Hitch - Max Trailer Wt. (lbs): N/A
• Wt Distributing Hitch - Max Tongue Wt. (lbs): 490
• Wt Distributing Hitch - Max Trailer Wt. (lbs): 4900
• Weight Information
• Curb Weight - Front (lbs): 2224
• Curb Weight - Rear (lbs): 1577
• Gross Axle Wt Rating - Front (lbs): 3100
• Gross Axle Wt Rating - Rear (lbs): 3850
• Gross Combined Wt Rating (lbs): 8800
• Gross Vehicle Weight Rating Cap (lbs): 5000
• Wheels
• Front Wheel Material: Steel
• Front Wheel Size (in): 16 x 7.0
• Rear Wheel Material: Steel
• Rear Wheel Size (in): 16 x 7.0
• Spare Wheel Material: Steel
• Spare Wheel Size (in): 16 x 7.0
