• 4-wheel drive w/4WDemand system
• 2-speed transfer case
• 3.91 axle ratio
• HD battery (2003)
• Skid plates-inc: front suspension, transfer case, fuel tank
• 121.9" wheelbase
• 5.1' double-wall box
• 5100# GVWR
• Front tow hook
• Independent coil-spring double-wishbone front suspension w/gas-filled shock absorbers
• Rear leaf-spring suspension w/staggered gas-filled shock absorbers
• Front stabilizer bar
• P225/75R15 mud + snow tires
• 15" x 6" styled steel wheels
• Full-size spare tire
• Pwr rack & pinion steering
• Pwr ventilated front disc/rear drum brakes w/rear load-sensing proportioning valve
• 4-wheel anti-lock brakes (ABS)
• 18.5 gallon fuel tank

• Black painted rear bumper
• Front/rear mudguards
• Aerodynamic multi-reflector halogen headlamps
• Rear center high-mounted stop lamp
• (4) full-size doors
• Black manual remote mirrors
• Tinted windshield glass
• Variable intermittent windshield wipers

• Front bucket seats w/adjustable headrests
• 60/40 split-folding rear bench seat w/outboard adjustable headrests
• Fabric seat trim
• Sculpted door trim w/cloth inserts, dual armrests, map pockets
• Full carpeting
• Center console-inc: dual covered storage, dual front/rear cup holders
• Tilt steering wheel
• Instrumentation-inc: coolant temp, warning lights
• Tachometer
• Rear seat heat ducts
• Deluxe AM/FM radio w/cassette-inc: (6) speakers
• Dual auxiliary pwr outlets
• Front maplights

• 4-wheel anti-lock brakes (ABS)
• Driver/front passenger airbags
• 3-point seat belts at outboard positions & center lap belt
• Front adjustable shoulder belt anchors at outboard positions
• Front seat belt pretensioners & force limiters
• Child restraint system lower anchors on rear outboard seats
• Rear door child safety locks
• Side-door impact beams

Bedliner (Over the Rail)

Carpet Floor Mats (4 piece set)

Convenience Package Includes: Power Windows/Door Locks & Keyless Entry, Glove Box Lamp,Fabric Door Trim,Front Personal Lamp,Cruise Control,Sliding Rear Window w/Privacy Glass,Power Outside Mirrors

High 4 Selector Swith

50 State Emissions

SR5 Color-Keyed Package Color-Keyed Front Bumper/Grille Surround/ Handle & Rear Bumper,Tilt Wheel & Inter. Wipers,Sunvisor w/Fabric Mirror & Extnsn, Tachometer,Twin Trip Meter,Digital Clock, ETR/Cass/CD w/6 Speakers,Air Conditioner, SR5 Badging

No Additional Gas

TRD Offroad Package Includes: 16" Aluminum Wheels w/P265/70R16 BF Goodrich Tires,Offroad Tuned Tokico Shocks,Color-Keyed Overfenders with IX/LL Packages or Black Overfenders without IX/LL Package,Rear Console Box,Diff Locks,TRD Offroad Badge

• Four Wheel Drive
• Tow Hooks
• Tires - Front On/Off Road
• Tires - Rear On/Off Road
• Steel Wheels
• Conventional Spare Tire
• Power Steering
• Front Disc/Rear Drum Brakes
• ABS
• Third Passenger Door
• Fourth Passenger Door
• Intermittent Wipers
• Variable Speed Intermittent Wipers
• Bucket Seats
• Pass-Through Rear Seat
• Rear Bench Seat
• Cloth Seats
• Adjustable Steering Wheel
• AM/FM Stereo
• Cassette
• Power Outlet
• Front Reading Lamps
• ABS
• Driver Air Bag
• Passenger Air Bag
• Child Safety Locks

• Mileage
• EPA Fuel Economy Est - City (MPG): 16
• EPA Fuel Economy Est - Hwy (MPG): 19
• Electrical
• Cold Cranking Amps @ 0° F (Primary): - TBD -
• Maximum Alternator Capacity (amps): 70
• Maximum Alternator Watts: 1050
• Cooling System
• Total Cooling System Capacity (qts): 10.0
• Weight Information
• Gross Axle Wt Rating - Front (lbs): - TBD -
• Gross Axle Wt Rating - Rear (lbs): - TBD -
• Curb Weight - Front (lbs): 2038
• Curb Weight - Rear (lbs): 1667
• Gross Vehicle Weight Rating Cap (lbs): 5100
• Gross Combined Wt Rating (lbs): 9000
• Trailering
• Dead Weight Hitch - Max Trailer Wt. (lbs): 3500
• Dead Weight Hitch - Max Tongue Wt. (lbs): 350
• Wt Distributing Hitch - Max Trailer Wt. (lbs): N/A
• Wt Distributing Hitch - Max Tongue Wt. (lbs): N/A
• Fifth Wheel Hitch - Max Trailer Wt. (lbs): - TBD -
• Fifth Wheel Hitch - Max Tongue Wt. (lbs): - TBD -
• Suspension
• Suspension Type - Front: Double-Wishbone
• Suspension Type - Rear: Leaf Spring
• Spring Capacity - Front (lbs): - TBD -
• Spring Capacity - Rear (lbs): - TBD -
• Axle Type - Front: Hypoid
• Axle Type - Rear: Hypoid
• Axle Capacity - Front (lbs): - TBD -
• Axle Capacity - Rear (lbs): - TBD -
• Axle Ratio (:1) - Front: 3.91
• Axle Ratio (:1) - Rear: 3.91
• Shock Absorber Diameter - Front (mm): 36
• Shock Absorber Diameter - Front (mm): 25
• Shock Absorber Diameter - Rear (mm): 36
• Shock Absorber Diameter - Rear (mm): 30
• Stabilizer Bar Diameter - Front (in): 1.02
• Brakes
• Brake Type: Pwr-Assisted
• Brake ABS System: Four-Wheel
• Disc - Front (Yes or ): Yes
• Front Brake Rotor Diam x Thickness (in): 11.6 x 0.87
• Drum - Rear (Yes or ): Yes
• Rear Drum Diam x Width (in): 11.6 x - TBD -
• Tires
• Front Tire Size: P265/70R16
• Front Tire Size: P225/75R15
• Rear Tire Size: P265/70R16
• Rear Tire Size: P225/75R15
• Spare Tire Size: P265/70R16
• Spare Tire Size: P225/75R15
• Front Tire Capacity (lbs): - TBD -
• Rear Tire Capacity (lbs): - TBD -
• Spare Tire Capacity (lbs): - TBD -
• Revolutions/Mile @ 45 mph - Front: - TBD -
• Revolutions/Mile @ 45 mph - Front: 744
• Revolutions/Mile @ 45 mph - Rear: - TBD -
• Revolutions/Mile @ 45 mph - Rear: 744
• Revolutions/Mile @ 45 mph - Spare: - TBD -
• Revolutions/Mile @ 45 mph - Spare: 744
• Wheels
• Front Wheel Size (in): 16 x 7
• Front Wheel Size (in): 15 x 6
• Rear Wheel Size (in): 16 x 7
• Rear Wheel Size (in): 15 x 6
• Spare Wheel Size (in): 16 x 7
• Spare Wheel Size (in): 15 x 6
• Front Wheel Material: Steel
• Rear Wheel Material: Steel
• Spare Wheel Material: Steel
• Steering
• Steering Type: Pwr Rack & Pinion
• Steering Ratio (:1), On Center: 19.4
• Steering Ratio (:1), At Lock: 3.5
• Turning Diameter - Curb to Curb (ft): 40.0
• Turning Diameter - Wall to Wall (ft): - TBD -
• Frame
• Frame Type: Ladder
• Fuel Tank
• Fuel Tank Capacity, Approx (gal): 18.5
• Fuel Tank Location: Midship
• Exterior Dimensions
• Wheelbase (in): 121.9
• Length, Overall w/o rear bumper (in): 202.9
• Width, Max w/o mirrors (in): 70.3
• Height, Overall (in): 67.5
• Overhang, Front (in): 31.5
• Overhang, Rear w/o bumper (in): 48.8
• Front Bumper to Back of Cab (in): - TBD -
• Cab to Axle (in): - TBD -
• Cab to End of Frame (in): - TBD -
• Ground to Top of Load Floor (in): - TBD -
• Ground to Top of Frame (in): - TBD -
• Frame Width, Rear (in): - TBD -
• Ground Clearance, Front (in): 10.0
• Ground Clearance, Rear (in): 10.0
• Cargo Area Dimensions
• Cargo Box Length @ Floor (in): 61.5
• Cargo Box Width @ Top, Rear (in): 57.9
• Cargo Box Width @ Floor (in): 57.9
• Cargo Box Width @ Wheelhousings (in): 40.9
• Cargo Box (Area) Height (in): 15.9
• Tailgate Width (in): - TBD -
• Cargo Volume (ft³): - TBD -
• Ext'd Cab Cargo Volume (ft³): - TBD -
• Interior Dimensions
• Passenger Capacity: 5
• Front Head Room (in): 38.8
• Front Leg Room (in): 42.8
• Front Shoulder Room (in): 53.9
• Front Hip Room (in): 49.6
• Second Head Room (in): 37.7
• Second Leg Room (in): 33.7
• Second Shoulder Room (in): 53.5
• Second Hip Room (in): 50.8
• Summary
• Vehicle Name: Toyota Tacoma
• Body Style: DoubleCab
• Body Code: 121.9
